Kapton® Tapes - ROHS Compliant
Kapton tape is made of polyimide film with heat resistant silicone adhesive to withstand temperature up to 500°F. Some of Kapton products are:
• 1 mil Kapton tape • 2 mil Kapton tape • 5 mil kapton tape
|
|
Low-Static-Kapton® Tapes
Low static kapton tape is made of 1 mil polyimide film backed by silicone adhesive.This tape can withstand temperature up to 500°F. Adhesive is 1.6mil thick. Total thickness of this product is 2.6±1 mil. Color is Amber and it comes in a 36 yds roll. This tape is ideal for environment where static discharge is a concern.
|
|
High-Temperature Kapton Discs
Kapton tape is cut to specific size for masking in Electrical and thermal insulation applications, in particular for the masking of Gold fingers on circuit boards during wave soldering. Total thickness is 2.6mil. Packaged in rolls of 500 to 2000 depending on the size.
|
 |
Solder Wave Masking Tapes
This tape made from Crepe paper. It can withstand a temperature up to 325°F for a very short time.. It has high resistance to heat and is residue free. They are packaged as 36 yds roll and are available in various widths.
|
|
Solder Wave Masking Discs
Featuring high quality, high heat resistance and no residue. Overlapped from 3/16 in. to 1 in. for rapid application. They are made from Crepe paper and can withstand a temperature up to 325°F.
|
